Product Summary
The AG15-48S05NTL is a general purpose gain block. The combination of flat OIP3 and noise figure performance over frequency makes it attractive for both narrow band and broadband applications. Superior thermal design allows the product to achieve +32 dBm OIP3 performance at a mounting temperature of +85°C with an associated MTBF of >1000 years3.
Parametrics
AG15-48S05NTL absolute maximum ratings: (1)Operating Case Temperature: -40 to +85°C; (2)Storage Temperature: -55 to +125°C; (3)DC Voltage: +5.5 V; (4)RF Input Power (continuous): +4 dBm.
Features
AG15-48S05NTL features: (1)60 - 3000 MHz; (2)+32 dBm Output IP3; (3)2.4 dB Noise Figure; (4)14 dB Gain; (5)+15 dBm P1dB; (6)MTBF >1000 Years; (7)SOT-89 SMT Package; (8)Single Bias Supply(+3.3 V or +4.5 V).
Diagrams
 |
